Bell mouth inlet, Quadro square static mixer for 200ml, 400ml and 600ml dual component epoxy type cartridges. Stepped nozzle outlet that can be used with tip luer adapter fitting and needle tips for more precision or left for high flow dispensing.

These mixer nozzles are suitable for 1:1 and 2:1 ratio two-component materials and have green inner elements and are constructed of high grade polypropylene. High quality nozzles for use with dual component cartridges. All products are industrial grade safe and silicone free.

---

Part ID: MCQ10-32T - MCQ 10-32T - 300377
Material: Polypropylene
Colour: Natural Outer, Green Elements
Inner Diameter: 10.7mm
Outer Diameter: 12.5mm
Elements: 32
Length: 220mm
Volume in Nozzle: 18.45ml
Details: Industrial Grade, Silicone Free
Commodity Code: 39269097
Origin: Europe
Brand: Sulzer Mixpac Medmix

---

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

---

• Part ID: MCQ 10-32T
• Material: Polypropylene
• Colour: Natural Outer, Green Elements
• Inner Diameter: 10.7mm
• Elements: 32 Length: 220mm
• Volume in Nozzle: 18.45ml
• Details: Industrial grade, Silicone Free


  Datasheet

High density moulded static mixer nozzles with bell attachment to cartridges or machines. Stepped end design for direct dispensing or attachment of reducer fitting when using small luer lock needle tips. Silicone free and industrial grade.

All nozzles are safe for use up to 100 psi pressure. Nozzles are precision manufactured for  industrial use. All nozzles are certified silicone-free to prevent contamination of any liquids dispensed from them.
