Bell mouth inlet, square helical static mixer for 200ml, 400ml, 600ml and 1500ml size dual component epoxy type cartridges. Luer style nozzle outlet that can be used with all precision dispense and needle tips.
These mixer nozzles are suitable for 1:1 and 2:1 ratio two-component materials. They have green inner elements and are constructed of high grade polypropylene. High quality mixer nozzles for use with dual side by side cartridges. All items are industrial grade safe and silicone free. 8.7mm ID x 24 mixing elements. Pricing is for a pack of 100 nozzles.
Part ID: ADMCQ 08-24L Material: Polypropylene
Colour: Natural Outer, Green Elements
Inner Diameter: 8.7mm
Outer Diameter: 10.5mm Elements: 24
Length: 147mm
Volume in Nozzle: 8.44ml
Details: Industrial Grade, Silicone Free Commodity Code: 39269097 Brand: ADL
Adhesive
Dispensing Ltd provide a wide range of equipment options for dispensing
almost all assembly fluids - from watery liquids, solvents, primers and
activators through to thick pastes, sealants, silicones, gels and
epoxies.
- Part ID: ADMCQ08-24L Material: Polypropylene
- Colour: Natural Outer, Green Elements
- Inner Diameter: 8.7mm
- Elements: 24
- Length: 147mm
- Volume in Nozzle: 8.44ml
- Details: Industrial grade, Silicone Free
![](/v/vspfiles/assets/images/qr-code-MCQ08-24L-TDS.jpg)
High density moulded static mixer nozzles with bell attachment to cartridges or machines. Stepped end design for direct dispensing or attachment of reducer fitting when using small luer lock needle tips. Silicone free and industrial grade.
All nozzles are safe for use up to 100 psi pressure. Nozzles are not for medical use but are precision manufactured for industrial use. All nozzles are certified silicone-free to prevent contamination of any liquids dispensed from them.
|
|
![](/v/vspfiles/templates/140/images/clear1x1.gif) |
![](/v/vspfiles/templates/140/images/DBox_Border_Left_Bottom.gif) |
![](/v/vspfiles/templates/140/images/clear1x1.gif) |
![](/v/vspfiles/templates/140/images/DBox_Border_Right_Bottom.gif) |
![](/v/vspfiles/templates/140/images/DBox_Border_Left_Bottom.gif) |
![](/v/vspfiles/templates/140/images/clear1x1.gif) |
![](/v/vspfiles/templates/140/images/DBox_Border_Right_Bottom.gif) |
![](/v/vspfiles/templates/140/images/DBox_Border_Left_MidDiv.gif) |
![](/v/vspfiles/templates/140/images/clear1x1.gif) |
![](/v/vspfiles/templates/140/images/DBox_Border_Right_MidDiv.gif) |
![](/v/vspfiles/templates/140/images/clear1x1.gif) |
Features
- Industry standard for 200/400/600/1500ml cartridges
- Silicone-free plastics
- Safe for use to 100 psi
- Stepped end
- Use on dual cartridges
- Supplied in sealed packs
|
|
